In order to improve working speed, cardboard table adopt on-line feeding.
Easy to change mold, suitable for different sizes of products.
The hot-melting glued tape auto conveying, cutting and four-angle sticking, forming the box in one process.
The auto alarm when the tape run out.
Parameters
Model
QTJ600
QTJ420
Box size max
400 x 600 x 150mm
350 x 450 x 120mm
Box size min
50x 100x 15mm
60x60x 10mm
Speed
50sheets/min
70sheets/min
Power
2.4Kw
2.5Kw
Power supply
380V/Hz
220V/Hz
Air consumption
0.2L7min0.4Mpa
8L7min0.8Mpa
Weight
1550Kg
1500Kg
Machine dimension
2350 x2500 x2300mm
2350 x 1450 x2200mm
About Us
Xinwei Machinery is a professional company designs and manufactures rigid box machinery and bookbinding machinery. Since the year of foundation in 2002, we have been dedicated in developing gift box making machine and book cover making machine. Currently, Xinwei is able to fully customize rigid box equipment mainly aimed at companies that need to batch production of set up boxes, clamshell boxes, cigar style boxes and other specific needs for shoe box, board game box, electronics box etc. Besides, our hardcover production line is also available to fulfil your need of manufacturing photo book, children book or more hardcover books throughout the processes of cardboard stitching, grooving, hardcover pressing and creasing etc. Xinwei is an ideal rigid box maker supplier to turn your vision into a compliant project.
